HOME FRAMES CR MO double butted tube KH-FM-02
  • yellow_frame_06
  • yellow_frame_04
  • yellow_frame_02
  • yellow_frame_01
  • DSC_1231-P2000
  • blue_frame_06
  • blue_frame_04
  • blue_frame_02
  • blue_frame_07
  • blue_frame_01
  • DSC_1230-P2000
  • yellow_frame_06
  • yellow_frame_04
  • yellow_frame_02
  • yellow_frame_01
  • DSC_1231-P2000
  • blue_frame_06
  • blue_frame_04
  • blue_frame_02
  • blue_frame_07
  • blue_frame_01
  • DSC_1230-P2000
yellow_frame_06 yellow_frame_04 yellow_frame_02 yellow_frame_01 DSC_1231-P2000 blue_frame_06 blue_frame_04 blue_frame_02 blue_frame_07 blue_frame_01 DSC_1230-P2000

KH-FM-02

▍ PREMIUM COLORWAYS

Every frame is a canvas for your personal riding style.
Choose from 10 stunning colorways across our premium Matt and Glossy finishes to customize your dream build:

• The Icons: Glossy Black ｜ Matt Black
• Street Stealth: Matt Army Green
• Racing Fuel: Glossy Ferrari Red
• Trendsetters: Glossy Tiffany Green ｜ Matt Miami Blue ｜ Matt Blue
• Attention Grabbers: Glossy Purple ｜ Matt Purple ｜ Matt Yellow
SHARE：
Own the Streets. Defy the Limits.
Engineered for those who push boundaries. This frame is the ultimate expression of our passion for BMX. Crafted with premium double-butted Chromoly steel and precision-tuned geometry, it strikes the perfect balance between featherlight agility and bulletproof strength. From heavy street drops to technical park grinds, it’s the rugged backbone you can always trust to command your ride.

▍ TECHNICAL SPECIFICATIONS
Component Details
Material 4130 Double-Butted Chromoly Steel (4130 DB CR-MO)
B.B. Type MID-BB
B.B. Width 73 mm
Seat Post Ø 25.4 mm
Top Tube Sizes 20.5" / 20.75" / 21"
▍ TECH HIGHLIGHTS
  • Double-Butted Technology
    Thicker tube walls at high-stress joints and thinner walls in the middle deliver maximum impact resistance and stress distribution without adding unnecessary weight.
  • Modern Street & Park Geometry
    Available in three signature top tube lengths to optimize responsiveness, snap, and manual stability, whether you are spinning tech street or blasting park quarters.
  • Bulletproof Crafts & Welding
    Reinforcements in critical high-stress zones paired with flawless, deep-penetration welding beads ensure exceptional torsional stiffness and ultimate fatigue resistance.


 A - TOP TUBE LENGTH : 20.5" / 20.75" / 21"

 B - STANDOVER HEIGHT : 8.74"

 C - HEAD TUBE ANGLE : 76.25°

 D - SEAT TUBE ANGLE :  79.6°

 E - CHAIN STAY LENGTH : 13.22"

2000x670
